TÜPRAŞ RAFİNERİSİ

Port Information

TUPRAS - TURKISH PETROLEUM REFINERIES INC

Installation

Address

Tupras Izmir Rafinerisi, Aliaga - IZMIR - TURKEY

Telephone

+90 232 498 5555

Fax

+90 232 498 5000

E Mail

iskele.izmir@tupras.com.tr

Person in Charge

N/A

Coordinates

LAT 38DEG 49'07'N    LONG 26DEG 57'36''E

Location

ALIAGA

Pilotage

Compulsory to all vessel over 500 GRT

Avaliable fm Ditas Contact  to "Aliaga Pilot"

Radio Frequency to contact; VHF Channel 16-13

24 hrs berthing/unberthing (except jetties #203, #204, #207, #208)

Towage

Compulsory to all vessels over 500 GRT

Avaliable fm Ditas Contact  to "Aliaga Pilot"

Radio Frequency to contact; VHF Channel 16-13

24 hrs berthing/unberthing (except jetties #203, #204, #207, #208)

Berth Information

Jetty No

201

202

203

204

205

206

207

208

Loa

317m

213m

317m

213m

95m

450m

200m

200m

Beam

-

-

-

-

-

-

-

-

Draught

17m

13m

9m

7m

7m

19,2m

17m

17m

Berthing

side alongside (mostly port side alongise unless otherwise stated by Pilot)

Restrictions

side alongside (mostly port side alongise unless otherwise stated by Pilot)

 -Max. Vessel Loa

285m

180m

100m

100m

95m

360m

230m

103m

 -Max. Vessel Draft

16m

12m

8m

6m

6m

17,5m

13m

6,5m

 -Max. DWT

150000

60000

5000

3500

3000

250000

44000

5000

Water Density

1,026 kg/cm3

Shore Gangway

available

available

N/A

N/A

N/A

available

available

N/A

Information

Bunker

available ex-shore line (except #207 & #208) - or at anchorage by barge

Fresh Water

available ex-shore line (except #207 & #208) - or at anchorage by barge

Slop

available (except #205 & #207 & #208)

Garbage

available and garbage cost payment is compulsory (optional only at 207 & 208)

Liquid Cargo

Name

Crude Oil - Fuel Oil - Gasoline     - Gasoil   - Naphtha - JetA1    - MTBE    - LPG

Avarage Rate P/H

10000 cbm - 2800 cbm - 2000 cbm     - 2500 cbm - 800 cbm - 1000 cbm - 800 cbm - 400 cbm

Connection

3 x 16"   - 4 x 12"  - 1x10" + 1x8" - 2 x 8"   - 1 x 10" - 1 x 10"  - 1x10"   - 1X8"

General Cargo

Name

NIL

Avarage Rate P/D

NIL

Working Hours

NIL

Shore Crane

NIL

LSGO Consume

All vessels within Turkish Port limits must consume LSGO even if they are at anchorage position either at berth. Vessels have 2 hours changeover opportunity from high sulphur bunker to low sulphur bunker both on entry & exit port limits.

In this respect, vessel has to consume LSGO on al below positions.

a) At Anchorage

b) From Pilot station or anchorage to terminal/berth

c) During discharging operation

d) From terminal to pilot point/open seas

ISPS INFORMATION

Security Level

1

STATEMENT NUMBER

2235070

OPERATOR

TÜPRAŞ RAFİNERİ TESİSİ (Aliağa-İZMİR)

PFSO

A. Levent BİÇER

Contact Details

Tel:0-232-498 5042 / Faks:0-232-498 5000 / Gsm:0-533-344 3925 / E-mail:levent.bicer@tupras.com.tr

Port Authority-Name of Person

TUPRAS IZMIR RAFINERISI            TUPRAS ISKELE(TERMINAL)

Contact Details

TEL:+90 232 498 5000      GSM:NIL  iskele.izmir@tupras.com.tr

Ambulance & Hospital

Emergency 112 - +90 232 616 8787(Aliaga State Hospital) or +90 232 324 6060(Private ambulance)  or agent AOH +90 533 496 03 24

Police

Emergency 155 - +90 232 616 2020

Cost Guard

VHF Channel 16  +90 232 616 1250(ext.2959)

Fire Brigade

Emergency 110 - +90 232 616 1045

Harbour Master

VHF Channel 16  +90 232 6161993
